Products Description
Main Technical Features:
◆ Centrally articulated structure with fully hydraulic power steering, providing a small turning radius.
◆ Constructed with high-quality alloy steel, utilizing advanced machining and heat treatment processes, and featuring innovative design to ensure a strong and durable vehicle structure.
◆ Equipped with CAN bus communication technology for fault self-diagnosis and real-time monitoring of vehicle operating status, ensuring system operation safety.
◆ Fitted with a video monitoring system to enhance equipment operation safety.
Technical Parameter
| Basic Dimensions | |
| Length | 8000mm~10796mm |
| Width | 1780mm~3050mm |
| Height | 2284 mm~2860mm |
| Boom Raising Time | 14s |
| Boom Lowering Time | 10s |
| Steering Angle | 65° |
| Maximum lifting height | 3910mm |
| Rear Axle Oscillation Angle | ±8° |
| Dumping Angle | ±40° |
| Turning Radius (Inner) | 4820mm~4970mm |
| Turning Radius (Outer) | 7290mm~9027 mm |
| Machine Weight | |
| Self weight of the whole machine | 11500kg~42500kg |
| Fully loaded gross weight | 21500kg~87500kg |
| Production Capacity | |
| Bucket Capacity (SAE Heaped) | 5.5m³~22m³ |
| Rated Load Capacity | 10,000kg~45,000kg |
| Maximum Traction Force | 169 kN~446kN |
| Gradeability | 25%, 3.3km/h |
| Travel Speeds (on horizontal road, fully loaded) | |
| Gear I (Forward/Reverse) | 4.4 km/h |
| Gear II (Forward/Reverse) | 9 km/h |
| Gear III (Forward/Reverse) | 15 km/h |
| Gear IV (Forward/Reverse) | 24.9 km/h |
